Steel Structure Low Price Portable Workforce Accommodation
Now that there are more and more high-rise buildings, the development of the construction industry is also very rapid. Workers must also be indispensable in the construction industry. Generally, construction sites are located in relatively remote places, and the housing of workers has become a problem that we need to solve. Packing the container house helps us solve this problem. Because container house is lighter in weight, it is very convenient to transport, and if the area is relatively large, several people can be seated in a room.
The accommodation container is the best solution to the problem of fast accommodation. It has a wide range of possibilities in terms of design, floor plan and number of floors. Our dormitory accommodation is usually used as guest dormitory, student dormitory, orphanage, military accommodation and workers accommodation .The main advantages of accommodation containers are safety, high insulation, comfort, modern design and affordable prices. The accommodation can include bedroom, leisure room, meeting room and seminar room, computer room, study room, canteen and kitchen, toilet and shower room and other functions according to customer requirements. If the customer needs, other options can be added, such as air conditioning, ventilation system, bunk beds and lockers.
Container Characters:
1) Materials can be reused
2) Can be freely combined
3) Heat and waterproof
4) Cost saving and convenient transportation
5) Convenient for relocation and transportation
6) Upgrade of all-steel framework is stronger
7) Provide guidance for installation
Main Item And Specification
| Item | Specification |
| Part 1 | Roof System |
| I. | Steel frame | Steel frame is Q235 galvanized fitting; |
| II. | Roof insulation | Ceiling is blue color steel pre-coated 0.4mm outside strong steel sheet;
With 50mm glass wool insulation material; |
| III. | Roof ceiling | Ceiling is shaped steel plate with different pattern |
| Part 2 | Floor System |
| I. | Steel frame | 3mm Galvanized Steel for main structure + 1.5mm square tube for secondary beam |
| II. | Floor | 15mm chipboard + PVC leather floor |
| Part 3 | Column System |
| I | Column | 2.5mm Shaped Galvanized Steel |
| Part 4 | Sandwich Wall System |
| I | Wall Panel | 50mm EPS Foam Sandwich Panel;
Outside color is light silver gray (0.35mm thickness steel );
Inside is white color steel (0.35mm thickness steel ). |
| Part 5 | Door & window system |
| I. | Door | Material: Steel door
Size: 2000*980mm(H*W) |
| II. | Window | Material: Aluminum alloy steel double hollow glass sliding window (including screens)
Size: 1200*1000mm(H*W) |
| Part 6 | Electric system |
| I. | Electric system | Includes ordinary LED light, A-SW double sockets 2set, A-SW air-switch 2 set,
Electrical box with safety protection device connecting cable for connecting; |
After sales service:
K-home promises after sales service promises to provide after-sales service and maintenance for customers
· Provide customers with detailed usage and maintenance manuals
· Quality problems occur during using, communicate and solve actively
· Committed to building a global network, better service for customers
· Regular return visits and maintenance to customers
Any questions, pls send an enquiry to us!
